Schulz Piston Compressor 7580HV30X-3 (932.9348-0)
Schulz 7580HV30X-3 Air Compressor: Built for Industrial Efficiency
The Schulz 7580HV30X-3 air compressor delivers industrial-grade performance and reliability for demanding applications. Featuring a 7.5 HP motor and an 80-gallon horizontal ASME-certified tank, this compressor ensures consistent airflow to power your tools and operations. With its durable construction and advanced engineering, it’s designed to meet the challenges of your workspace.
Why Choose the Schulz 7580HV30X-3 Air Compressor?
- Robust Design: Heavy-duty cast-iron pump and powder-coated tank for enhanced durability.
- High Performance: Operates at a maximum working pressure of 175 PSI with a flow rate of 20.1 CFM, ensuring efficient performance.
- Safety Assured: Equipped with ASME safety relief valves, a pressure gauge, and an enclosed metal belt guard.
- Convenient Maintenance: Includes features like a manual condensate drain and balanced drive pulleys for easy upkeep.
Specifications
- Motor: 7.5 HP three-phase, 208-230/460V
- Maximum Pressure: 175 PSI
- Flow Rate: 20.1 CFM
- Tank Size: 80-gallon horizontal ASME-certified
- Dimensions: 56" x 23" x 45"
- Weight: 553 lbs
Expanded Features
1. Durable Construction
The Schulz 7580HV30X-3 is built with high-quality materials and an anticorrosive finish, ensuring long-lasting performance even in tough environments.
2. Powerful and Efficient Operation
The 7.5 HP motor and horizontal tank design deliver consistent airflow, making it suitable for industrial tasks requiring reliable power.
3. Safety and Maintenance Made Easy
Equipped with ASME-certified components and user-friendly features like the manual condensate drain, this compressor prioritizes safety and convenience.
Industrial Power You Can Trust
Whether for service stations, manufacturing facilities, or repair shops, the Schulz 7580HV30X-3 air compressor delivers unmatched performance. Backed by CET’s fastest shipping and best customer service, it’s the perfect addition to your industrial workspace.
Shipping Disclaimer
Shipping times may vary based on location. Contact CET for expedited delivery and installation services.
Related Models
Other Schulz Piston Air Compressors
Compare the Schulz Piston compressor range below — every model is CET Verified and supported by our technical team. Need help choosing? Ask for a CET sizing match.
| Motor | Displacement | FAD @ Max | Tank | Power | View |
|---|---|---|---|---|---|
| 5 HP | 20 CFM | 15.6 CFM | 80 Vertical | 3-PHASE | View |
| 5 HP | 20 CFM | 15.6 CFM | 80 Vertical | 1-PHASE | View |
| 5 HP | 20 CFM | 15.9 CFM | 80 Vertical | 3-PHASE | View |
| 5 HP | 20 CFM | 15.6 CFM | 80 Horizontal | 3-PHASE | View |
| 5 HP | 20 CFM | 15.9 CFM | 80 Vertical | 1-PHASE | View |
| 5 HP | 20 CFM | 14.2 CFM | Vertical | 3-PHASE | View |
| 5 HP | 20 CFM | 14.2 CFM | Horizontal | 1-PHASE | View |
| 5 HP | 20 CFM | 15.6 CFM | 80 Horizontal | 1-PHASE | View |
| 5 HP | 20 CFM | 15.8 CFM | 80 Vertical | 1-PHASE | View |
| 5 HP | 20 CFM | 14.2 CFM | Vertical | 1-PHASE | View |
| 5 HP | 20 CFM | 14.2 CFM | Horizontal | 3-PHASE | View |
| 7.5 HP | 30 CFM | 20.1 CFM | 80 Horizontal | 3-PHASE | Current |
| 7.5 HP | 30 CFM | 20.1 CFM | 80 Horizontal | 1-PHASE | View |
| 7.5 HP | 30 CFM | 20.1 CFM | 80 Vertical | 1-PHASE | View |
| 7.5 HP | 30 CFM | 21.6 CFM | 80 Vertical | 1-PHASE | View |
| 7.5 HP | 30 CFM | 20.1 CFM | 80 Vertical | 3-PHASE | View |
| 7.5 HP | 30 CFM | 21.6 CFM | 80 Vertical | 3-PHASE | View |
| 10 HP | 40 CFM | 28 CFM | 120 Vertical | 3-PHASE | View |
| 10 HP | 40 CFM | 28 CFM | 120 Horizontal | 3-PHASE | View |
| 10 HP | 40 CFM | 28.4 CFM | 120 Horizontal | 3-PHASE | View |
| 15 HP | 60 CFM | 45.2 CFM | 120 Horizontal | 3-PHASE | View |
| 15 HP | 60 CFM | 45.2 CFM | 120 Vertical | 3-PHASE | View |
| 20 HP | 80 CFM | 58 CFM | 102 Horizontal | 3-PHASE | View |
| 20 HP | 80 CFM | 58.4 CFM | 120 Horizontal | 3-PHASE | View |
Not sure which Schulz Piston compressor fits your shop? Call or text 586-210-0555 for a CET sizing match.
Common Questions
Frequently Asked Questions
- How much CFM do I actually need?
- Add up the air demand of every tool that runs at once and add headroom for leaks and growth. This model delivers 20.1 CFM (FAD) at 175 psig. Undersizing causes pressure drops; oversizing wastes energy. Call or text 586-210-0555 with your tool list and CET will size it.
- Single-phase or three-phase — which do I need?
- This unit is wired three-phase, typical of industrial buildings and more efficient for heavy use. Confirm your building’s available service before ordering — voltage and phase must match. Unsure? Call or text 586-210-0555.
- Piston or rotary screw — which is right for me?
- Piston (reciprocating) compressors are ideal for intermittent duty and lower cost of entry. If you run air most of the day, a rotary screw is better for continuous duty. CET carries both — call or text 586-210-0555 to compare.
- Do I need an air dryer with it?
- For finishing, painting, and instrument air, yes — a refrigerated dryer removes moisture that rusts piping and ruins finishes. CET can match a Schulz ADS dryer to this compressor’s output; call or text 586-210-0555.
