Description
Sagola Classic Pro XD 1.60 mm HVLP Spray Gun
1.60 mm · HVLP
HVLP — 1.60 mm
Industrial finishes and primers, HS primers, fillers and waterborne — maximum saving, low overspray.
Perfect atomization, maximum transfer
The best price/quality ratio in conventional primer spray guns — built for a professional Sagola response in every sector.
New body, improved ergonomics
A redesigned body for maximum ergonomics and comfort, a wider range of responses, and strict compliance with the most demanding regulations.
Versatile across sectors
Industry (high-quality finishes and primers), wood (lacquers, varnishes, backgrounds, waterborne clearcoats) and decoration (enamels and varnishes).
HVLP & EPA versions
The HVLP version for maximum saving and low overspray; the EPA version for high performance in finishes.
Built to last, easy to clean
No joints between air and paint, an internal air distributor, stainless-steel nozzles and needles, a chrome-plated body, a single-shaft design with fewer parts, a one-piece packing gland and no O-rings.
Every cap in the Sagola Classic Pro XD range
Five caps span finishes, primers, high-build and fillers — 21 EPA and HVLP for compliant finishing, and 25, 36 and 28 for high-thickness primers and fillers.
Finishes & primers
High-quality finishes, lacquers and dyes through to HS primers and high-thickness work.
Compliant, low overspray
Industrial finishes and primers, HS primers, fillers and waterborne — maximum saving, low overspray.
High-build primers
HS primers and high-thickness primer work.
Fillers
Fillers and thick layers, clearcoats and waterborne paints.
Viscous primers
Viscous primers and forge-effect finishes.
Technical data
| Weight without cup | 480.8 g. |
|---|---|
| Weight with cup | 665 g. |
| Dimensions with cup | 17.7 x 10.5 x 33.3 cm. |
| Dimensions without cup | 17.9 x 1.9 x 17.7 cm. |
| Air inlet couplings | BSP 1/4" M |
| Maximum design pressure | 8 bar |
| Maximum recommended inlet pressure (working pressure) | 2 bar |
| Maximum recommended application distance HVLP | 12 - 15 cm. |
| Maximum recommended application distance 21 EPA and 25/36/28 | 18 - 20 cm. |
| Air consumption Aircap 21 EPA | 225 L/min. |
| Air consumption Aircap HVLP | 355 L/min. |
Parts diagram, manuals & spares
Exploded parts breakdown for the Sagola Classic Pro XD, downloadable manuals & brochures, and every needle, nozzle and air cap available as a spare.
