C.A. Technologies CPR-FE Pressure Feed Spray Gun Parts Manual
This page provides the official parts manual for the C.A. Technologies CPR-FE Pressure Feed Spray Gun. Use this page to review air cap and fluid tip combinations, identify replacement parts, and order genuine components.
Model Covered: C.A. Technologies CPR-FE
Gun Specs: Pressure feed spray gun • pressure reduced and HVLP air cap options • fan control: 60-1317 • air consumption: 11 CFM with 23-2101 / 13.5 CFM with 23-1301 • fluid range: 0.8 mm – 1.7 mm
Download the PDF Parts Manual
Download Full CPR-FE Parts Manual (PDF)
About the CPR-FE Spray Gun
The CPR-FE gun comes equipped with both a pressure reduced air cap and an HVLP air cap for shops that need flexibility across different coating applications and compliance requirements.
- 23-2101 is the pressure reduced air cap and consumes 11 CFM at 29 PSI gun inlet
- 23-1301 is the HVLP air cap and consumes 13.5 CFM at 29 PSI gun inlet
- Both air cap options are used across the 0.8 mm through 1.7 mm fluid range shown in the manual
- 60-1317 is the fan control used on this model
Actual fluid nozzle and air cap combinations are determined by the application. Gun inlet pressures may vary as required by the material and setup.
Operation & Maintenance Notes
- Connect the air supply hose at the handle of the gun.
- Connect a pressurized fluid supply to the gun fluid inlet.
- Use the fluid control knob to fine tune flow rate by limiting needle travel.
- Adjust fan width with the fan control knob. Turning clockwise narrows the fan.
- Routine cleaning and maintenance are essential for proper gun performance.
- Have repair kit 10-140 available before gun disassembly.
Available Spray Gun Configurations
- CPR-FE — Smart Pack
- CPR-FE-303R2 — CAT Pack with 51-303 Aluminum Pressure Cup
- CPR-FE-PPSR2 — CAT Pack with PPS Cup Setup
Air Cap / Fluid Tip / Needle Chart
| Pressure Reduced Air Cap | HVLP Air Cap | Orifice Size | Fluid Tip Part Number | Fluid Needle Part Number |
|---|---|---|---|---|
| 23-2101 | 23-1301 | 0.8 mm | 33-0208 | 40-1808 |
| 23-2101 | 23-1301 | 1.0 mm | 33-0210 | 40-1810 |
| 23-2101 | 23-1301 | 1.2 mm | 33-0212 | 40-1810 |
| 23-2101 | 23-1301 | 1.3 mm | 33-0213 | 40-1812 |
| 23-2101 | 23-1301 | 1.4 mm | 33-0214 | 40-1813 |
| 23-2101 | 23-1301 | 1.5 mm | 33-0215 | 40-1815 |
| 23-2101 | 23-1301 | 1.7 mm | 33-0217 | 40-1817 |
Recommended Fluid Nozzle / Air Cap Selection
| Material Type | Typical Materials | Recommended Setup | Maximum Pattern Width | CFM |
|---|---|---|---|---|
| Very Thin | Inks, dyes, solvents, stains | 0.8 mm x 2101 or 1301 1.0 mm x 2101 or 1301 |
23-2101 13" 23-1301 12" |
23-2101 11 CFM 23-1301 13.5 CFM |
| Thin | Lacquers, enamels, primers, sealers | 1.2 mm x 2101 or 1301 1.3 mm x 2101 or 1301 |
23-2101 13" 23-1301 12" |
23-2101 11 CFM 23-1301 13.5 CFM |
| Medium | Automotive base coat, enamels, primers, epoxies, urethanes, automotive clear coat | 1.3 mm x 2101 or 1301 1.4 mm x 2101 or 1301 1.5 mm x 2101 or 1301 |
23-2101 13" 23-1301 12" |
23-2101 11 CFM 23-1301 13.5 CFM |
| Heavy | Heavy body primers, high solid enamels, high solid automotive coatings, adhesives | 1.5 mm x 2101 or 1301 1.7 mm x 2101 or 1301 |
23-2101 13" 23-1301 12" |
23-2101 11 CFM 23-1301 13.5 CFM |
Replacement Parts Breakdown (Click Part Numbers)
| Item | Part Number | Description |
|---|---|---|
| 1 | See Air Cap Chart | Air Cap |
| 2 | See Air Cap Chart | Fluid Nozzle Tip |
| 3 | 60-35 | Head Insert |
| 4 | 98-8026 | O-Ring |
| 5 | 60-137 | Seal Ring |
| 6 | 98-5125 | O-Ring |
| 7 | 98-5225 | O-Ring |
| 8 | 60-1320 | Air Valve Assembly |
| 9 | 60-1317 | Fan Control |
| 10 | 60-1312 | Fluid Control Knob |
| 11 | 60-211 | Needle Return Spring |
| 12 | 60-104 | Air Inlet Fitting |
| 13 | 60-1319 | Air Control Assembly |
| 14 | 60-2111 | Trigger |
| 15 | 60-126 | Fluid Inlet |
| 16 | 60-128 | Locknut |
| 17 | 60-1315 | Shoulder Screw |
| 60-1329 | Needle Seal Cartridge | |
| 19 | 60-1301-CPR | Gun Handle |
Included Packs & Accessories
- CPR-FE Smart Pack Includes:
- CPR-FE-303R2 Includes:
- CPR-FE-PPSR2 Includes:
Need Help Identifying a Part?
If you’re unsure which part you need for your C.A. Technologies CPR-FE spray gun, use the part breakdown above or contact CET with your item number and spray gun configuration.
