C.A. Technologies FE-Line Fine Finish HVLP Spray Gun — 1.0mm Setup (FEFF-10-1310)
Finish Excellence Line | Lightweight Fine Finish HVLP | US Made
The FE-Line Fine Finish (FEFF) is C.A. Technologies' lightweight ergonomic HVLP pressure feed spray gun, designed around the technology of the CAT SLP. The 1.0mm setup (FEFF-10-1310) pairs the 23-1310 air cap with the 33-0210 fluid tip and 40-1810 needle — the recommended configuration for very thin materials including inks, dyes, solvents, and stains where a slightly larger orifice than the 0.8mm is needed for increased flow while maintaining precise HVLP atomization.
The FEFF's patented 12 Point Plenum design creates a more balanced, even cone of air as fluid is atomized — producing more uniform particles and a flatter, more consistent finish compared to conventional HVLP designs. Combined with all stainless steel fluid passages, a 15 oz. lightweight body, and 65% transfer efficiency or better, the FE-Line Fine Finish is built for operators who demand professional results with every pass.
Technical Specifications
| Setup | FEFF-10-1310 (1.0mm) |
| Air Cap | 23-1310 |
| Fluid Tip | 33-0210 — 1.0mm (.040") |
| Needle | 40-1810 |
| Air Consumption | 13.5 CFM @ 29 PSI |
| Max Gun Inlet Pressure | 29 PSI |
| Maximum Pattern Width | 12" |
| Weight | 15 oz. |
| Feed Type | Pressure Feed Only |
| Transfer Efficiency | 65% or better (HVLP compliant) |
| Fluid Passages | All Stainless Steel |
| Fan Control | 60-1317 |
| Origin | US Made |
| Repair Kit | 10-140 |
| HVLP Air Cap Test Gage | 23-1310-G |
| Recommended Applications | Very Thin — Inks, Dyes, Solvents, Stains |
Why the FE-Line Fine Finish?
Most HVLP guns rely on a standard air diffusion ring that creates uneven high and low pressure spikes around the fluid stream — resulting in inconsistent particle sizes and finishes. The FE-Line Fine Finish solves this with its patented 12 Point Balanced Plenum design, which distributes air evenly across all 12 points as the fluid is atomized. For very thin materials like inks, dyes, and solvents, this precision translates directly into a more uniform particle cloud, better coverage consistency, and a cleaner finished surface.
- Optimized for very thin materials — 1.0mm orifice delivers precise, controlled flow for inks, dyes, solvents, and stains
- Patented 12 Point Plenum Design — creates a more even cone of air for superior atomization uniformity vs. conventional HVLP guns
- Lightweight ergonomic body — weighs only 15 oz., reducing operator fatigue in production environments
- 65% transfer efficiency or better — meets HVLP compliance requirements at 29 PSI inlet
- All stainless steel fluid passages — compatible with inks, dyes, solvents, and other thin coating chemistries
- US Made — designed and manufactured by C.A. Technologies (Coating Atomization Technologies)
Available Outfits & Configurations
The FE-Line Fine Finish is available in CAT Pack, 2 Quart outfit, and tank outfit configurations. CAT Packs include the gun, air caps, nozzle/needle sets, and tools in a carrying case.
| Configuration | Type | Description |
|---|---|---|
| CP-FEFF-303R2 | CAT Pack | FEFF gun, air caps, nozzle/needle sets, 1 QT aluminum pressure cup w/regulator, tools, carrying case |
| CP-FEFF-PPSR2 | CAT Pack — 3M™ PPS™ | FEFF gun, air caps, nozzle/needle sets, 950 mL 3M™ PPS™ pressure cup w/regulator, lids/liners, tools, case |
| FEFF-130 | 2 Quart Outfit (Economy) | Includes 5' hose assemblies |
| FEFF-600 | 2 Quart Outfit (Bandit) | Includes 5' hose assemblies |
| Tank Outfits | 2.5, 5, 10, 12.5, 15 Gallon | Includes 25' hose assemblies. Available in multiple tank sizes. |
All FE-Line Fine Finish Setup Options
Each FEFF setup uses a matched air cap paired to a specific fluid orifice. Select the setup that matches your coating material and application requirements.
| Setup | Orifice | Air Cap | Fluid Tip | Needle | Recommended For |
|---|---|---|---|---|---|
| FEFF-08-1308 | 0.8 mm | 23-1308 | 33-0208 | 40-1808 | Stains, Dyes ★ Eliminates Haloing & Motting |
| FEFF-10-1310 (this page) | 1.0 mm | 23-1310 | 33-0210 | 40-1810 | Very Thin — Inks, Dyes, Solvents, Stains |
| FEFF-12-1312 | 1.2 mm | 23-1312 | 33-0212 | 40-1812 | Thin — Lacquers, Enamels |
| FEFF-13-1313 | 1.3 mm | 23-1313 | 33-0213 | 40-1813 | Single Stage, Base Coat, Clear Coat ★ Top Coat |
| FEFF-14-1314 | 1.4 mm | 23-1314 | 33-0214 | 40-1814 | Single Stage, Base Coat, High Solid Clears, Sealer, Primer |
| FEFF-15-1315 | 1.5 mm | 23-1315 | 33-0215 | 40-1815 | High Solid Clears, Sealer, Primer, Epoxy |
| FEFF-17-1317 | 1.7 mm | 23-1317 | 33-0217 | 40-1817 | Sealer, Primer, Wash Primer, Epoxy |
Download the Full Parts Manual
Replacement Parts (Click Part Numbers to Order)
Keep your FE-Line Fine Finish running at peak performance with genuine C.A. Technologies replacement parts. Parts marked with * are included in repair kit 10-140.
| Item | Part No. | Description |
|---|---|---|
| 1 | 23-1310 | Air Cap (1.0mm) |
| 2 | 33-0210 | Fluid Nozzle Tip — 1.0mm (.040") |
| 12 | 40-1810 | Fluid Needle — 1.0mm |
| 3 | 60-35 | Head Insert |
| 4 | 98-8026 | O-Ring* |
| 5 | 60-137 | O-Ring* |
| 6 | 60-1301-CL | Gun Handle |
| 7 | 98-5125 | O-Ring* |
| 8 | 98-5225 | O-Ring* |
| 9 | 60-1320 | Air Valve Assembly |
| 10 | 60-1317 | Side Port Control (Fan Control) |
| 11 | 60-1312 | Fluid Control Knob |
| 13 | 60-211 | Needle Return Spring* |
| 14 | 60-104 | Air Inlet Fitting |
| 15 | 60-1319 | Air Control |
| 16 | 60-2111 | Trigger |
| 17 | 60-126 | Fluid Inlet |
| 18 | 60-128 | Locknut |
| 19 | 60-1315 | Trigger Pivot Set (2) |
| 20 | 60-1329 | Needle Seal Cartridge* |
Deterministic linking: Every hyperlink above is taken directly from the PDF's embedded annotation layer. Any part without an embedded PDF link is plain text.
Need Help?
Not sure which FEFF setup is right for your coating material or application? Contact CET with your material type and viscosity. We'll help you select the correct air cap, fluid tip, and needle combination before you order.
