C.A. Technologies Lynx 100C Conventional Spray Gun — 1.2mm / 21-2266-3 Pressure Setup (L100C-12-2266-3)
100 Series Conventional General Purpose | US Made
The Lynx 100C (L100C) is C.A. Technologies' high quality general purpose conventional spray gun, available in both pressure and siphon feed configurations. The L100C-12-2266-3 setup pairs the 31-0612 fluid nozzle (1.2mm) with the 21-2266-3 pressure air cap — the highest-output pressure air cap in the standard 0.6–1.8mm range, delivering 16.2 CFM and a full 15" pattern width. An ideal choice for medium viscosity materials including automotive base coat, enamels, primers, epoxies, urethanes, and clear coat where maximum coverage and productivity are the priority.
Built with a forged aluminum body and all stainless steel fluid passages, the Lynx 100C delivers conventional air spray dependability across a wide range of coatings and industries. Its broad air cap selection — covering siphon feed, pressure feed, and internal mix configurations — makes it one of the most versatile conventional spray guns in the C.A. Technologies lineup.
Technical Specifications
| Setup | L100C-12-2266-3 |
| Air Cap | 21-2266-3 — Pressure Feed, 16.2 CFM @ 50 PSI |
| Fluid Nozzle | 31-0612 — 1.2mm (.046") |
| Needle | 40-1110 (110) |
| Feed Type | Pressure Feed |
| Max Inlet Pressure | 50 PSI |
| Air Consumption | 16.2 CFM @ 50 PSI |
| Maximum Pattern Width | 15" |
| Gun Type | Conventional (non-HVLP) |
| Body | Forged Aluminum |
| Fluid Passages | All Stainless Steel |
| Fan Control | 60-1500 (included) |
| Origin | US Made |
| Repair Kit | 10-106 |
| Recommended Applications | Medium — Automotive Base Coat, Enamels, Primers, Epoxies, Urethanes, Clear Coat |
Best for This Setup
The L100C-12-2266-3 is the highest-output pressure feed configuration available in the standard 0.6–1.8mm fluid tip range, and the right choice when pattern coverage and production speed are the priority over air consumption. The 21-2266-3 delivers 16.2 CFM and a full 15" fan — the widest pattern in the pressure feed lineup — making it ideal for spraying large flat surfaces like automotive panels, cabinet doors, sheet metal components, and industrial parts where maximizing coverage per pass directly reduces cycle time. The 1.2mm stainless nozzle paired with pressure feed keeps fluid delivery consistent and responsive even at higher line pressures, with enough orifice precision to avoid excessive overspray on base coats and medium-viscosity enamels. If you're running a pressure pot or pressure cup system and need maximum pattern width without stepping up to a 1.5mm or 1.8mm orifice, this is the configuration to reach for.
Why the Lynx 100C?
The Lynx 100C is C.A. Technologies' answer to conventional spray gun dependability — a workhorse gun built for operators who need reliable, consistent performance across a wide variety of coating applications. The forged aluminum body keeps it lightweight and durable, while the all stainless steel fluid passages ensure compatibility with everything from thin inks and dyes to heavy body primers and adhesives.
- Forged aluminum body — lightweight, durable, and built for production use
- Stainless steel fluid passages — compatible with the full range of coatings from thin to thick
- Broad air cap selection — 21 air cap options across siphon, pressure, and internal mix configurations let you optimize for any application
- Available with carbide tipped fluid nozzles — for abrasive material applications that would wear standard stainless steel nozzles
- Internal mix capability — the 21-200 and 21-2201 air caps enable internal mix spraying for specific application needs
- Flexible outfit options — available with 1 QT siphon cup, 1 QT pressure cup, 2 quart outfit, or tank outfits from 2.5 to 15 gallons
- US Made — designed and manufactured by C.A. Technologies (Coating Atomization Technologies)
Available Outfits & Configurations
| Part Number | Type | Description |
|---|---|---|
| OL100C-303R2 | 1 QT Pressure Cup | Lynx 100C with 1 QT aluminum pressure cup |
| OL100C-301 | 1 QT Siphon Cup | Lynx 100C with 1 QT aluminum siphon cup |
| OL100C-130 | 2 Quart Outfit (Economy) | Includes 5' hose assemblies |
| OL100C-600 | 2 Quart Outfit (Bandit) | Includes 5' hose assemblies |
| Tank Outfits | 2.5, 5, 10, 12.5, 15 Gallon | Includes 25' hose assemblies. Available in multiple tank sizes. |
All Lynx 100C Air Cap Options
The Lynx 100C supports an extensive range of air caps across siphon, pressure, and internal mix configurations. Select the air cap that matches your fluid viscosity, feed type, and required pattern width.
Siphon Feed
| Air Cap | Fluid Tip Range | Max Inlet | CFM |
|---|---|---|---|
| 21-2166 | 0.6 – 1.8mm | 50 PSI | 5 CFM |
| 21-2266 | 0.6 – 1.8mm | 50 PSI | 12 CFM |
| 21-2266T | 0.6 – 1.8mm | 50 PSI | 12 CFM — Teflon |
| 21-2366 | 0.6 – 1.8mm | 50 PSI | 12 CFM |
| 21-2466 | 0.6 – 1.8mm | 50 PSI | 15 CFM |
| 21-2467 | 2.2mm | 50 PSI | 15 CFM |
| 21-2268 | 2.8mm | 50 PSI | 15 CFM |
Pressure Feed
| Air Cap | Fluid Tip Range | Max Inlet | CFM |
|---|---|---|---|
| 21-2163 | 0.6 – 1.8mm | 50 PSI | 8 CFM |
| 21-2263 | 0.6 – 1.8mm | 50 PSI | 14 CFM |
| 21-2266-3 (this page) | 0.6 – 1.8mm | 50 PSI | 16.2 CFM |
| 21-2266-3T | 0.6 – 1.8mm | 50 PSI | 16.2 CFM — Teflon |
| 21-2167 | 2.2mm | 50 PSI | 14.5 CFM |
| 21-2267 | 2.2mm | 50 PSI | 15 CFM |
| 21-2168 | 2.8mm | 50 PSI | 14 CFM |
| 21-2766B | 1.0 – 1.8mm | 50 PSI | 8 CFM |
Internal Mix
| Air Cap | Fluid Tip Range | Max Inlet | CFM |
|---|---|---|---|
| 21-200 | 1.5 – 1.8mm | 50 PSI | 5.2 CFM — requires 21-1583 base & 21-1584 ring |
| 21-2201 | 2.2mm | 50 PSI | 5.2 CFM — requires 21-1583 base & 21-1584 ring |
Download the Full Parts Manual
Replacement Parts (Click Part Numbers to Order)
Keep your Lynx 100C running at peak performance with genuine C.A. Technologies replacement parts. Parts marked with * are included in repair kit 10-106.
| Item | Part No. | Description |
|---|---|---|
| 1 | 21-2266-3 | Air Cap — Pressure, 16.2 CFM |
| 2 | 31-0612 | Fluid Nozzle Tip — 1.2mm (.046") |
| 13 | 40-1110 (110) | Fluid Needle — 1.0mm–1.3mm |
| 3 | 31-2201 | Fluid Nozzle Body |
| 4 | 60-L11C | Nozzle Body Carrier |
| 5 | 61-1005 | Seal* |
| 6 | 60-12C | Air Cap Adapter |
| 7 | 60-131 | O-Ring* |
| 8 | 60-1124 | Lynx Gun Body Conventional |
| 9 | 98-0109 | Allen Plug |
| 11 | 60-119 | Seal* |
| 12 | 60-201 | Rear Bushing |
| 14 | 60-204 | Needle Return Spring* |
| 15 | 60-205 | Spring Seat* |
| 16 | 60-202 | Fluid Control Knob |
| 17 | 60-104 | Air Inlet Fitting |
| 18 | 60-1510 | Inlet Air Control |
| 19 | 60-1520 | Air Valve Assembly |
| 21 | 60-302 | Air Valve Poppet |
| 22 | 60-125 | Seal* |
| 23 | 61-1003 | Air Valve Spring* |
| 24 | 60-126 | Fluid Inlet |
| 25 | 60-128 | Locknut |
| 26 | 60-124 | Seal* |
| 27 | 60-1400 | Needle Seal* |
| 28 | 60-2101 | Trigger |
| 29 | 60-1033 | Trigger Pivot Set |
Need Help?
Not sure which air cap or fluid nozzle combination is right for your coating material? Contact CET with your material type, viscosity, and feed preference. We'll help you select the correct Lynx 100C setup before you order.
