C.A. Technologies FE-Line Fine Finish (FEFF) Pressure Feed Spray Gun Parts Manual
This page provides the official parts manual for the C.A. Technologies FE-Line Fine Finish (FEFF) Pressure Feed Spray Gun. The FEFF is a dedicated HVLP pressure feed gun featuring matched air caps — each air cap is paired to a specific fluid orifice size for optimized atomization at every fluid range. Use this manual to identify your air cap and fluid nozzle combination, confirm part numbers, and order genuine replacement parts directly from CET.
Model: FE-Line Fine Finish (FEFF) • Feed Type: Pressure Feed • HVLP Only
Air Consumption: 13.5 CFM @ 29 PSI • Fan Control: 60-1317 • Repair Kit: 10-140
Download the PDF Parts Manual
HVLP Air Cap & Fluid Nozzle Chart
The FE-Line Fine Finish uses a matched air cap system — each air cap is sized to a specific fluid orifice for precise HVLP atomization. Select the air cap that matches your fluid tip size. All air caps are pressure feed only.
| Orifice Size | Air Cap | Fluid Tip | Needle | Max Gun Inlet | SCFM | Standard in CAT Pack |
|---|---|---|---|---|---|---|
| 0.8 mm (.022") | 23-1308 | 33-0208 | 40-1808 | 29 PSI* | 13.5 | ✓ Included |
| 1.0 mm (.040") | 23-1310 | 33-0210 | 40-1810 | 29 PSI* | 13.5 | — |
| 1.2 mm (.046") | 23-1312 | 33-0212 | 40-1812 | 29 PSI* | 13.5 | — |
| 1.3 mm (.052") | 23-1313 | 33-0213 | 40-1813 | 29 PSI* | 13.5 | ✓ Included |
| 1.4 mm (.055") | 23-1314 | 33-0214 | 40-1814 | 29 PSI* | 13.5 | — |
| 1.5 mm (.059") | 23-1315 | 33-0215 | 40-1815 | 29 PSI* | 13.5 | — |
| 1.7 mm (.070") | 23-1317 | 33-0217 | 40-1817 | 29 PSI* | 13.5 | ✓ Included |
*Air cap test gages are available to confirm HVLP compliance. Gun inlet pressures may vary as required by application. HVLP Air Cap Test Gages for FE-FF Guns: 23-1308-G, 23-1310-G, 23-1312-G, 23-1313-G, 23-1314-G, 23-1315-G, 23-1317-G, 23-1319-G, 23-1322-G
Nozzle Selection by Material
| Material Type | Typical Materials | Fluid Orifice x Air Cap | Max Pattern Width | Feed |
|---|---|---|---|---|
| Very Thin | Inks, dyes, solvents, stains | 1.0 mm x 1310 | 12" | Pressure |
| Thin | Lacquers, enamels, primers, sealers | 1.0 mm x 1310 1.3 mm x 1313 |
12" | Pressure |
| Medium | Automotive base coat, enamels, primers, epoxies, urethanes, clear coat | 1.3 mm x 1313 1.5 mm x 1315 1.7 mm x 1317 |
12" | Pressure |
| Heavy | Heavy body primers, high solid enamels, high solid automotive coatings, adhesives | 1.5 mm x 1315 1.7 mm x 1317 |
12" | Pressure |
Replacement Parts (Click Part Numbers to Order)
Keep your FE-Line Fine Finish running at peak performance with genuine C.A. Technologies replacement parts. Parts marked with * are included in repair kit 10-140.
| Item | Part No. | Description |
|---|---|---|
| 1 | See Air Cap Chart | Air Cap |
| 2 | See Air Cap Chart | Fluid Nozzle Tip |
| 3 | 60-35 | Head Insert |
| 4 | 98-8026 | O-Ring* |
| 5 | 60-137 | O-Ring* |
| 6 | 60-1301-CL | Gun Handle |
| 7 | 98-5125 | O-Ring* |
| 8 | 98-5225 | O-Ring* |
| 9 | 60-1320 | Air Valve Assembly |
| 10 | 60-1317 | Side Port Control (Fan Control) |
| 11 | 60-1312 | Fluid Control Knob |
| 12 | See Air Cap Chart | Fluid Needle |
| 13 | 60-211 | Needle Return Spring* |
| 14 | 60-104 | Air Inlet Fitting |
| 15 | 60-1319 | Air Control |
| 16 | 60-2111 | Trigger |
| 17 | 60-126 | Fluid Inlet |
| 18 | 60-128 | Locknut |
| 19 | 60-1315 | Trigger Pivot Set (2) |
| 20 | 60-1329 | Needle Seal Cartridge* |
Kit Configurations & Accessories
| Part No. | Description | CP-FEFF Smart Pack | CP-FEFF-303R2 | CP-FEFF-PPSR2 |
|---|---|---|---|---|
| 51-303 | 1 QT Aluminum Pressure Cup | — | ✓ | — |
| 91-460 | 950 mL 3M™ PPS™ Pressure Cup | — | — | ✓ |
| 91-462 | Lids and Liners (25 Pack) | — | — | ✓ |
| 91-475 | #18 PPS Adapter | — | — | ✓ |
| 52-5R2 | Pressure Cup Regulator | — | ✓ | ✓ |
| 98-0104 | 3/8" Socket | ✓ | ✓ | ✓ |
| 98-0112 | Ratchet Wrench | ✓ | ✓ | ✓ |
| 60-8001 | Gun Wrench | ✓ | ✓ | ✓ |
| 98-0113 | Gun Cleaning Brush | ✓ | ✓ | ✓ |
Need Help Identifying a Part?
If you're unsure which air cap, fluid tip, or replacement part you need for your FE-Line Fine Finish spray gun, contact CET with your model configuration and item number from the diagram. We'll help confirm compatibility before you order.
